【Features】
【Features】
| Input | Thermal couples of K、J、T、E、B、R、S、N、C (ITS、90) |
| Thermistor PT 100Ω, 2-wire or 3-wire | |
| Voltage ±60mVDC or ±10VDC | |
| Current 0 to 24mADC | |
| Accuracy | Parameter table |
| A/D Resolution | 16 Bits |
| Sampling Time | <200ms |
| Power Supply | DC 10~36V |
| Max. Load | MAX LOOD、 (V-10) 10.02(Ω) |
| Output Resolution | 0.6uA(15Bits) |
| Output Response Time | <200ms |
| Common Mode Rejection Ratio (CMRR) | >80dB |
| Battery Compatibility | En50081-2 . En50082-2 |
| Isolation | 4KV between input and output |
| Operating temperature | -40 to 85℃ |
| Humidity | 0 to 90%RH |
| Dimensions | 75mm(w) X 87mm(H) X 18.5mm(D) |
| nput Type | Max. Range | Precision |
|---|---|---|
| Thermocouple J | -50 to 1000 ℃ (-58 to 1832)°F | ±1℃ |
| Thermocouple K | -50 to 1370℃ (-58 to 2498)°F | ±1℃ |
| Thermocouple T | -270 to 400 ℃ (-454 to 752)°F | ±1℃ |
| Thermocouple E | -50 to 960 ℃ (-58 to 1780)°F | ±1℃ |
| Thermocouple B | 0 to 1750 ℃ (32 to 3182)°F | ±2℃ (註1) |
| Thermocouple R | -50 to 1750 ℃ (-58 to 3182)°F | ±2℃ |
| Thermocouple S | -50 to 1750 ℃ (-58 to 3182)°F | ±2℃ |
| Thermocouple N | -50 to 1300 ℃ (-58 to 2372)°F | ±2℃ |
| Thermocouple C | -50 to 1800 ℃ (-58 to 3272)°F | ±2℃ |
| Pt100 | -200 to 600 ℃ (-328 to 1112)°F | ±0.2℃ |
| mV | -60mV to 60mV | ±0.01mV |
| Voltage (annotate1) | -10 to 10Vdc | ±1mV |
| Current (annotate1) | 0 to 24mAdc | ±10 u A |
